Gladen RS 08

Specifications Gladen RS08:

• DC resistance (Rdc):

  3,5 Ω

• Nominal impedance (ZN):

  4 Ω

• Resonance frequency (fs):

  39,6 Hz

• Voice coil diameter:

  1,5 inch

• Mechanical Q factor (Qms):

  5,96

• Electrical Q factor (Qes):

  0,55

• Total Q factor (Qts):

  0,5

• Moving mass (Mms):

  57,3 g

• Effective piston area (Sd):

  221 cm²

• Mechanical resistance (Rms):

  2,5 kg/s

• Compliance (Cms):

  0,28 mm/N

• Force factor (BL):

  9,5 Tm

• Equivalent air volume (Vas):

  18,1 dm³

• SPL 2,83V/1m:

  88 dB
